FRACTAL DESIGN Core 1000 USB 3.0 Vifter: 1x 120mm Front, 1x USB 2.0, 1x USB 3.0. mATX, mITX
You have to log in to shop/see prices.
|
|
FRACTAL DESIGN Core 1000 USB 3.0 Vifter: 1x 120mm Front, 1x USB 2.0, 1x USB 3.0. mATX, mITX
SKU:
FD-CA-CORE-1000-USB3-BL
-
Power supply
0W
-
Type
Midi Tower
-
Color
Black
|
Description
Specifications
Related products
Expert Reviews
Core 1000 USB 3.0
The Fractal Design Core Series offers a unique combination of design, cooling performance and value.
The Core 1000 USB 3.0 brings forth many features usually only seen in more expensive and larger cases. It supports long graphics cards up to 350mm in length as a result of the innovative, vertical HDD mounting bracket. The front panel is easily removable and pre-fitted with fan filters to ensure a dust free interior.
The sleek black interior is contrasted with white expansion slots while all HDD mountings are fitted with anti-vibration silicone grommets for optimal silence.
- Simple yet elegant mesh front panel allowing for increased airflow through the case
- Optimized for performance in a compact, micro-ATX form factor with multiple cooling options
- NEW: 1 x USB 3.0 with internal connector, 1 x USB 2.0
- One Silent Series R2 fan included: 1 x 120mm in front
- A total of 3 fan slots (1 x 120mm in front, 1 x 92mm in rear, 1 x 120mm in side panel)
- Innovative HDD positioning with mounts the HDD or SSDs vertically on the mounting bracket with anti-vibration silicone grommets
- Supports long graphics cards up to 350mm in length
- Supports various combinations of drive sets ups: 3 x 2.5" SSD, 2 x 3.5" HDD or 1 x 2.5" SSD + 1 x 3.5" HDD
- Dust filter for front fan position
Specifications
- mATX, Mini ITX, DTX motherboard compatibility
- Drive bay capacity: 2 - 3.5" HDD or 3 - 2.5" SSD or 1 - 3.5" HDD + 1 - 2.5" SSD
- 2 - ODD slots
- 1 - FDD slot, using convertor in ODD slot (convertor included)
- 4 expansion slots with sleek white painted brackets
- Supports graphic card up to 350mm in length with one HDD mounted
- Supports graphic card up to 210mm in length with two/three HDD mounted
- Supports CPU coolers up to148mm in height
- Supports full size ATX PSU, maximum length about 185 mm if an optical drive is mounted
- Case dimensions (WxHxD): 175 x 355 x 420mm
- Net weight: 4.1 kg
- Package dimensions (WxHxD): 225 x 415 x 475mm
- Package weight: 5 kg
Cooling System
- 3 total fan positions - 1x 120mm in front, 1x 92mm in rear, 1x 120mm in side panel
- 1 – 120mm Silent Series R2 fan included (front)
| Formfaktor | Midi Tower |
| Modell/Type | PC |
| Produktfarge | Svart |
| Støttet systemdisk formfaktorer | DTX, Micro ATX, Mini-ITX |
| Antall 3.5" bays | 2 |
| Antall utvidelsesspor | 4 |
| Siderute | No |
| Innebygde høyttalere | No |
| Tilbakestillingsknapp | Yes |
| LED-indikatorer for kommunikasjon | Ja |
| Maksimal høyde CPU-kjøler | 14,8 cm |
| Maksimal lengde grafikkort | 35 cm |
| Strømforsyning medfølger | No |
| Støttede formfaktorer strømforsyning | ATX |
| Antall USB 2.0-porter | 1 |
| Antall USB 3.2 Gen 1 (3.1 Gen 1)Type-A-porter | 1 |
| Lydkontakter | Ja |
| Lydutgang | Ja |
| Frontvifte installert | 1x 120 mm |
| Maksimale frontvifter | 1 |
| Frontviftediameter som støttes | 120 mm |
| Antall sidevifter som støttes (maks.) | 1 |
| Sideviftediametere som støttes | 120 mm |
| Antall bakvifter som støttes (maks.) | 1 |
| Bakre viftediametere som støttes | 92 mm |
| Støttede HDD-størrelser | 2.5,3.5" |
| Bredde | 175 mm |
| Dybde | 420 mm |
| Høyde | 355 mm |
| Vekt | 4,1 kg |
| Pakkebredde | 230 mm |
| Pakkedybde | 473 mm |
| Pakkehøyde | 415 mm |
| Pakningsvekt | 5 kg |
| Manuale/bruksanvisning | Yes |
